ホーム /製品/放出のブロー形成機械/270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V

270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V

$34,200/sets 1-2 sets
価格
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
ビデオ送信検査: 提供された
機械試験報告書: 提供された
コアコンポーネント: PLC,エンジン,ベアリング,ギアボックス,ギア
プラスチック加工: PP、HDPE、ABS、PVC、PE、EVA、PE/PP、HDPE/PP
原産地: 江蘇省、中国
brand name: DAWSON
電圧: 440V/415V/380V/220V
寸法(長さ*幅*高さ): 4.4*3.4*3.6
クランプ力（kn）: 270
PLCブランド: WISETECHについて
ねじL/D比: 24
ネジ径（mm）: 90
生産量 (kg/h): 130
オートメーション: 自動
スクリュー加熱ゾーン数: 4
スクリュー加熱力(kW): 10
押出機モーター出力(kW): 30
模具 プレートのサイズ (幅) (mm): 660
模具 プレート サイズ (高さ) (ミリ): 680
空気圧（MPA）: 0.8
空気消費量(m³/分): 2.2
ダイヘッド加熱電力(kW): 8
電力(kw): 67
重量(T): 11.3
主なセールスポイント: 操作が簡単
保証: 1年
ブロー成形タイプ: 放出のブロー形成機械
最大適用サイズ: 10~30L
冷却水圧: 0.6 MPa
水の消費量: 100 L/min
パリソン制御システム: M00G 200ポイント
カビ材料: P20, 2316, S136H, アルミとベリリウム銅
言語設定: 中国および英国操作のパネル
提供される指示: 中国語および英語の指示
労働需要: 1~2 operetor
サンプル提供: 必要であれば
基本情報
お支払配送条件
製品の説明
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 0
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 1
10-30L Plastic Jerry Can Extrusion Blow Molding Machine
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 2
Electronic Parts
Parison Control system
MOOG 200 points
Micro computer control system
WISETECH
Temperature Controller
WISETECH
Auxiliary Relay
OMRON
contactor
Schneider
Main Power Switch
Schneider
Approach switch
Schneider
Electric motor
W&N
Inverter
INNOVANCE
Hydraulic Parts
Oil pump
SUMITOMO
Valve
YUKEN
Oil pump and connection
YUKEN
Sealed part
DZ
Air Control System
Cylinder
AIRTAC
Air Valve
AIRTAC


Click here to send us messages >>Send Inquiry...

270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 3
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 4
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 5
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 6
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 7
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 8
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 9
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 10
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 11
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 12
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 13
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 14
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 15
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 16

DAWSON MACHINE & MOULD GROUP

located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
injection molding machine, blow molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience, to confirm new theory and new design, we are forming a unique competitive advantage of our owns.
The machines from our company carry good quality and effective after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 17
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 18
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 19
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 20
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 21
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 22

Q: Can we visit your factory?
Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong International Airport. We can pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by video.

Q: How can we get the exact price of plastic machine?
Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with quotation.

Q: Do you provide any spare parts with machine?
Yes, we offer all necessary spare parts before shipment.(contact us for packing list )

Q: How about your after-sale service ?
We offer manual instruction and engineer training before loading,after shipment we provide 24 HRS online support, video technical support or field installation assist.

Q: What is the lead time?
For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual production cycle will vary according to the degree of customization.)

Q: What is the warranty period for your machine ?
12 months warranty for components and technical support .

Q: Do you provide custom machines?
Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers products to meet customer' needs.

Q: How can we install the machine when it arrives?
We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the customer's employees.

Q: What's DAWSON's advantage?
DAWSON provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we can source the auxiliary equipment for customers. We can ship the full set of machines after testing in our factory. It will save a lot of cost and time.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 23
